Lifting Slings by Shaw Belting

Serving Industry Since 1942
SHAW produces nylon and polyester lifting slings, both available in “natural,” white or yellow latex-treated for high visibility.
All SHAW slings have red yarn interwoven into the core of the web, as a built-in warning signal. If the sling surface is worn
through or cut, the red yarn becomes exposed, indicating that the sling should be replaced. SHAW sews a nylon tag on every
sling, which states the belt width, length and load capacity.

SHAW BELTING EYE & EYE SLING

Type III and IV, our most popular slings, are versatile enough to be used for Vertical,
Basket and Choker hitches.

SLING PART EYE EYE RATED CAPACITIES (LBS)* BASE 3’ ADDITIONAL
WIDTH NUMBER WIDTH LENGTH VERTICAL CHOKER BASKET SLING PER FOOT
1” EE1-61 1” 9” 1,275 1,020 2,550 CALL CALL
1” EE1-91 1” 9” 1,615 1,290 3,230 CALL CALL
1” EE2-61 1” 9” 2,350 1,880 4,700 CALL CALL
1” EE2-91 1” 9” 2,940 2,350 5,880 CALL CALL
2” EE1-62 2” 9” 2,550 2,040 5,100 CALL CALL
2” EE1-92 2” 9” 3,230 2,585 6,460 CALL CALL
2” EE2-62 2” 9” 4,640 3,715 9,280 CALL CALL
2” EE2-92 2” 9” 5,880 4,705 11,760 CALL CALL
3” EE1-63 1.5” 12” 3,825 3,060 7,650 CALL CALL
3” EE1-93 1.5” 12” 4,845 3,875 9,690 CALL CALL
3” EE2-63 1.5” 12” 6,960 5,570 13,920 CALL CALL
3” EE2-93 1.5” 12” 8,820 7,055 17,640 CALL CALL
4” EE1-64 2” 12” 5,100 4,080 10,200 CALL CALL
4” EE1-94 2” 12” 6,460 5,165 12,920 CALL CALL
4” EE2-64 2” 12” 9,280 7,420 18,560 CALL CALL
4” EE2-94 2” 12” 12,920 10,335 25,840 CALL CALL
F.O.B. Manufacturer
EE1= 1 ply of web Minimum sling order is $50.00
EE2= 2 ply of web
All Straps Are Custom Made, No Returns

SHAW BELTING ENDLESS SLING

SLING PART RATED CAPACITIES (LBS)* BASE 3’ ADDITIONAL
WIDTH NUMBER VERTICAL CHOKER BASKET SLING PER FOOT
1” EN1-61 2,400 1,920 4,800 CALL CALL
1” EN1-91 3,210 2,560 6,420 CALL CALL
1” EN2-61 4,800 3,840 9,600 CALL CALL
1” EN2-91 6,400 5,120 12,800 CALL CALL
Type 2” EN1-62 4,800 3,840 9,600 CALL CALL
V 2” EN1-92 6,400 5,120 12,800 CALL CALL
2” EN2-62 9,600 7,680 19,200 CALL CALL
2” EN2-92 12,400 9,920 24,800 CALL CALL
3” EN1-63 6,600 5,280 13,200 CALL CALL
3” EN1-93 9,000 7,200 18,000 CALL CALL
3” EN2-63 12,200 9,760 24,400 CALL CALL
3” EN2-93 17,000 13,600 34,000 CALL CALL
4” EN1-64 8,800 7,040 17,600 CALL CALL
4” EN1-94 12,000 9,600 24,000 CALL CALL
4” EN2-64 16,300 13,040 32,600 CALL CALL
Replacement “S” hooks. 35¢ each 4” EN2-94 22,000 17,600 44,000 CALL CALL
EN1= 1 ply of web F.O.B. Manufacturer
EN2= 2 ply of web Minimum sling order is $50.00
All Straps Are Custom Made, No Returns
